产品介绍

设备主要特性

1、本设备为极柱端子焊接机，主要通过火焰融化集群极柱与电池极柱套的密封连接；

2、本设备配置了焊接质量检测工位，主要是通过焊接高度来检测焊接的可靠性；

3、本设备的焊枪升降、左右移动均采用伺服控制，以达到数控要求；

4、本设备的模具采取恒温循环水冷却，以避免模具温度过高烫坏塑壳等不良产品的出现。

设备主要参数

1、设备效率≥3只/分钟

2、适于塑壳范围：长：187——410mm

                 宽：127——176mm

                 高：170——250mm

3、设备尺寸：长：3500mm

             宽：1800mm

             高：2360mm

4、主要耗能：电源：220V / 380V / 440V * 3相* 50 / 60Hz（可选）

电耗：约12.6KW

                压缩空气：5-6KGf/cm²

                循环水：2.5L/min

                氧气：300——450Kpa

                天然气：20——50Kpa

CNC terminal welding machine (1*6 type double station)

Product introduction

Main characteristics of equipment

1, the device is a pole terminal welding machine, mainly through the flame melting cluster pole and battery pole sleeve sealing connection;

2, the equipment is equipped with welding quality testing station, mainly through the welding height to test the reliability of welding;

3, the equipment of the welding torch lifting, left and right movement are servo control, in order to meet the numerical control requirements;

4. The mold of this equipment is cooled by constant temperature circulating water to avoid the appearance of bad products such as mold temperature is too high.

Main parameters of equipment

1, equipment efficiency ≥3 / min

2, suitable for plastic shell range: length: 187 -- 410mm

Width: 127 -- 176mm

Height: 170 -- 250mm

3, equipment size: length: 3500mm

Width: 1800mm

Height: 2360mm

4, the main energy consumption: Power supply: 220V / 380V / 440V * 3 phase * 50/60Hz (optional)

Power consumption: about 12.6KW

Compressed air: 5-6KGf/cm²

Circulating water: 2.5L/min

Oxygen: 300 -- 450Kpa

Natural gas: 20 -- 50Kpa
